Lubricant Additives

Lubricant Additives

	Viscosity Index Improver (Liquid)		E.P. Additive for Gear Oil
	Pour Point Depressant (PPD)		Calcium Petroleum Sulphonate (TBN 300)
	Engine Oil Additive (DI Package)		Dispersant
	Hydraulic Oil Additive		2T Oil Additive
	ATF Additive		Thermic Oil Additive
	Defoamer		Sodium Petroleum Sulphonate
	Phinolic Antioxidant (Low Temperature)		Multi-functional Fuel Additive
	Aminic Antioxidant (High Temperature)

Viscosity Index Improver

It is an oil concentrate of an olefinic copolymer and is recommended primarily as a Viscosity Index Improver for crankcase lubricants particularly where excellent shear stability is desired.

As applies to all viscosity index improvers, there is some loss in viscosity and in viscosity index due to the shear forces encountered in engine operation. In this respect, it exhibits outstanding characteristics as evidenced by an average viscosity loss of 12 % at 100o C for SAE 15W-40 crankcase oils in over the road service.

In laboratory Caterpillar diesel engine Engine tests, it would be expected to perform at least comparable to the poly iso butylene type V.I. Improvers and superior to the polymeric ester types in regard to piston cleanliness. Being an all hydrocarbon material, it behaves in the same manner as the base oil component in MS Sequence engine tests. Multiviscosity oils containing VII have tendency for lower Octane Requirements Increase (ORI) than other V.I. Improvers.

TIPICAL INSPECTION DATA	PROPERTIES	TIPICAL VALUES
	Viscosity @ 100 oC., CST.	1300
	Flash Point , oC., min.	180
	Density @ 15 oC.	0.875
	Color, ASTM	< 2.5
	% shear loss in DIN 51382 (30 passes)	14
	Thickening in 500 N base oil @ 5 % treat level @ 100 oC. min	3.5
	Shear Stability Index	35

DOSAGE REQUIREMENTS IN VARIOUS GRADES USING SOLVENT REFINED GROUP I BASE OILS HAVING SUITABLE BASE OIL VISOSITY TO MEET LOW TEMPERATURE CHARACTERISTICS.

SAE GRADES	% DOSAGE
20W 50	6.5
20W 40	4.0
15W 40	8.0
10W 30	10.0

Pour Point Depressant

This is a broad spectrum pour point depressant for neutral paraffinic mineral base oils and also for reclaimed base oils. It is basically poly Alkyl Methyl Methacrylate type polymer in mineral base oils. It is compatible with conventional broad range commercially available & complete range of V.I. Improvers.

SPECIFICATIONS	TYPICAL VALUES
Appearance	Viscous liquid
Color, ASTM ,max.	2.0
Sp. Gravity @ 27 oC	0.88
Viscosity @ 100 oC ., cSt.	100
Flash Point COC oC, min.	180

Pour Point Depression

The depression achieved will depend upon the type of lubricant for which PPD is to be used. Typical results with various dosages on some products are listed below.

SPECIFICATIONS TEST RESULTS (POUR POINT IN OC )
% W/W	S.N. 150 OIL	S.N. 500 OIL	HIGH WAXED OIL
0.0	(-)6	(-)3	(+)15
0.15	(-)21	(-)18	(+)9
0.30	(-)27	(-)24	(+)3
0.40	(-)36	(-)27	(+)3

Engine Oil Additive Di Package

Introduction

It has been designed for formulating heavy duty diesel engine lubricants meeting API CD/CF (Multigrades and Monogrades) performance levels.

PERFORMANCE PACKAGE
Performance Level	API CF ( 9 TBN)
Treat Rate % wt.	6.00
Viscosity Index Improver	Non Dispersant V.I. Improver
Base Stocks	Group I base oils
SAE Viscosity Grades	15W-40, 20W-40, 20W-50, 10W, 20W, 30W, 30, 40, 50

Engine Test containing 6.00 % wt E.O.A. in group I base oils and Non Dispersant V.I. Improvers is characterized by excellent piston deposits control and low bearing weight loss in CRC L - 38.

DI package can be used in following treat rates to achieve the following credentials.

API PERFORMANCE	SAE GRADES	DOSAGE % W/W	BASE OILS USED
API CD	Multigrade	5.5	Group I
API CD	Monograde	5.25	Group I
API CC	Multi/Monograde	3.0	Group I
API CB	Monograde	2.7	Group I

Multigrade: SAE 15W-40, 20W-40, 20W-50.

Monogrades: SAE 20W, 30, 40, 50

TYPICAL PROPERTIES
SPECIFICATION	TYPICAL VALUES	TEST METHOD
Density @ 25 °C, gm/cm3	1.0	ASTM D 4052
Flash Point °C (PM), min.	170	ASTM D 92
Viscosity at 100 °C, cSt.	75	ASTM D 445
Total Base Number (TBN)	145	ASTMD 2896

Typical Finished oil test results with additive as follows:

API PERFORMANCE	CF/CD	CF/CD	CC	CB
DI PACKAGE	6.00	5.5	3.0	2.7
VII	As required	As required	As required	As required
Basestocks	Balance	Balance	Balance	Balance
Total	100.00	100.00	100.00	100.00

ELEMENTS	CF/CD	CF/CD	CC	CB
Boron % wt	0.002	0.002	0.001	0.001
Calcium % wt	0.00	0.00	0.00	0.00
Copper % wt	0.00	0.00	0.00	0.00
Magnesium % wt	0.241	0.228	0.134	0.112
Nitrogen % wt	0.020	0.19	0.011	0.010
Phosphorus % wt	0.056	0.055	0.031	0.025
Silicon, ppm	3	3	2	2
Zinc, % wt	0.062	0.059	0.034	0.026
Sulphated ash, % wt	1.12	1.05	0.62	0.51
TBN mg/KOH/g	11.0	10.5	6.2	5.0

Magnesium content % wt.	3.62	ASTM D 4951
Nitrogen Content % wt.	0.315	ASTM D 5291
Phosphorus content, % wt.	0.86	ASTM D 4927
Zinc content % wt.	0.95	ASTM D 4927
Sulphated Ash % wt.	16.87	Calculated
Boron % wt.	0.038

Defoamer

It is an ashless type defoamer for industrial mineral and synthetic oil based

	Gear Oils		Automotive Oils
	Turbine Oils		Compressor Oils
	Hydraulic Oils

It should be evaluated at Dosage level of 0.01 % to 0.05% by weight of the total formulations. Unlike conventional silicon oil defoamers, our defoamer shows excellent stability and compatibility with all the systems.

SPECIFICATION	TYPICAL VALUES
Viscosity @ 100 oC., cSt.	5
Appearance	Clear to slight hazy liquid
Density @ 20.5 oC., cSt.	0.87
Flash Point , oC.	Below room temperature
Dispersibility	Dispersible in aqueous and non aqueous fluids

Handling and Storage

IT should store at room temperature. Heating and freezing has no adverse effect on the product performance. Refer to the material safety data sheet for additional safety and handling information.

Phinolic Antioxidant (Low Temperature)

Chemical Composition: Mixed Alkylated Hindered Phenols.

Performance

Due to different alkyl chain length of hindered phenol groups it inhibits oxidation of all types of molecules having Olefinic groups effectively. It has good compatibility with all other types of additives and gives synergistic effect along with Aminic type antioxidants as compared to DBPC.

TYPICAL PHYSICAL PROPERTIES
Appearance	Yellow liquid
Color ASTM	2.0
Density @ 30oC	0.90
Pour Point o C	(-) 12
Flash Point o C	95

ADVANTAGES OVER DBPC/BHT
PROPERTIES	DBPC	PHINOLIC A.O
Nature of product at room temp.	Solid crystalline	Liquid
Dissolution temp. ° C	65	liquid form
Working temp. range oC	60 to 110	(-)30 to 200
Evaporation losses at 125 oC	9.8	0.25
% wt. for 3 hours
Evaporation losses at 180 oC	80	5.90
% wt. for 3 hours

Test Results

RBOT (ASTM D-2272) Induction time @ 1.0% wt in 150 N oil

ANTIOXIDANTS	INDUCTION TIME, MINUTES
DBPC	180
Antioxidant	400+
0.25% of DBPC & Aminic each	300
0.25% of A.O & Aminic each	460
0.25% of DBPC & Z.D.D.P. each	240
0.25% of A.O & Z.D.D.P. each	380+

Aminic Antioxidant (High Temp)

Chemical Composition: Long Chain Amines type

Sr. No.	TEST	SPECIFIACTION	RESULTS
1	Appearance	CLEAR SLIGHTLY COLORED LIQUID	PASSES
2	Content of diphenyl amine %	< = 0.99	0.82
3	Total Base number, mg KOH/g	172 - 192	182
4	Basic Nitrogen, %	4.35 – 4.80	4.55
5	Kinematic viscosity @ 40° C, cSt	225 – 450	405
6	Clarity of solution	Clear Solution	PASSES
7	Color value, ASTM D-1500	<= 2.0	0.5
8	Water	<=0.15	0.04

Effective Temperature Range: 150° C to 450 o C

Applications

It is an effective Antioxidant for
	Gasoline & Diesel Engine Oils
	Industrial Oils
	Automotive/Industrial Greases
	Fuels (H.S.D. & M.S.)

Advantages over conventional Antioxidants

	Working range	It works upto to 450 oC. where as DBPC dissociates above 110 oC. and other conventional antioxidants have limited working temperature range.
	Compatibility	Good compatibility with all other types of additives and gives synergistic effect along with Aminic, Phenolic and Phosphates type antioxidants.

Test Results: RBOT (ASTM D-2272) Induction time @ 1.0% wt in 150 N (group I) base oil

ANTIOXIDANTS	INDUCTION TIME, MINUTES
DBPC	180
CONVENTIONAL AMINIC ANTIOXIDANT	430
Our Antioxidant	490
0.25% of DBPC & COMM. Aminic each	380
0.25% of DBPC & A.O each	460
0.25% of COMM. AMINIC & Z.D.D.P. each	380
0.25% of A.O & Z.D.D.P. each	450
0.25% of mixed alkylated A.O & long amine A.O each	460

E. P. Additive for Gear Oil

It has been specially formulated to give excellent antiwear and extreme pressure properties along with thermal, oxidation and rust characteristics (covering copper and copper alloys) to cover a broad range of applications of gear oil applications. It should be blended with highly refined base stocks to meet API GL4, GL5, GL2 and IS 8406 (1993) when blended in suitable base stock & desired viscosity grades.

Performance: Lubricants formulated with this additive package work for heavy duty enclosed gear drives with splash and circulatory type lubrication systems under heavy shock load conditions. It also gives dependable performance for continuous service at operating temperature upto 160 °C. It is also useful for antifriction bearings subjected to heavy shock loads.

SPECIFICATIONS	TYPICAL VALUES
Color	Amber liquid
Viscosity @ 100 oC., cSt., min.	7
Flash Point, COC oC, min.	110
Sp. Gravity @ 27 oC	0.91
Nitrogen Content %, min	1.0
Sulphur content % wt., min	22.0
Phosphorus % wt., min	0.8

Dosage: To formulate suitable grades in group i base oils

	API GL 4 (AUTOMOTIVE GEAR OIL)	2.0
	API GL 5 (AUTOMOTIVE GEAR OIL)	4.0
	IS 8406 (INDUSTRIAL GEAR OIL)	1.5

Calcium Petroleum Sulphonate (TBN 300)

Physical And Chemical Properties

This is a brownish red liquid and non-toxic. The flash point is 190. It can react with strong oxidants.

SPECIFICATIONS
CHARACTER	LIMITS	TYPICAL
Calcium Content %Wt.	2.8 - 3.0	2.9
Sulfar % Wt	2.6 - 3.7	3.2
Total Base Number	25 - 30	29
Soap Content	38 - 42	40
Oil Content % Wt.	60	52
Flash Point Coc ° C	200	>200
Color Astm Dd	4.5	---
Water Content, Max	0.5	0.23
Viscosity @ 100° C, Cst	45	57

Applications

The product has the advantages of excellent neutralization power & high temperature detergency and rust preventive property. It can be mainly used for blending high and medium grade lubricating oil used in internal combustion engines, marines and the engines which use fuel with high sulfur content so that lacquer and carbon residue deposits accumulated in the combustion chamber of the engines are not only greatly reduced, but also the cleanliness of the pistons can be maintained. Corrosion to the engine parts by acidic matters also can be prevented and its service time can be prolonged. Better compounding synergistic effect can be obtained with the addition of ashless dispersant, anti-oxidant and corrosion inhibitor. The quantity of the product to be added into lubricating oil is from 1.5% to 3.0% in formulating engine oil and 5 to 10 % in formulating Marine engine oils.

Dispersant

Introduction

Dispersants typically contain a hydrocarbon attached to an amine or alcohol containing polar group. The hydrocarbon "tail" serves to solubilize the molecule in lubricant base stock, while the polar group serves to attract the polar contaminants resulting from the lube breakdown. The dispersant forms millions of minute structures in the lubricant base stocks, which contain a highly polar core and disperse enormous amounts of polar contaminants. These contaminants are products of oxidation, which serves as precursors to varnish carbon and sludge formation as well as already-formed varnish/carbon/sludge deposits. The dispersed contaminants are held in "solution" in the basestock while already-formed deposits are cleaned off the metal and elastomer surfaces. Both the suspended precursors and deposits will readily pass through commonly used filters. Ultimately, when these cores are saturated, the dispersant can no longer pick up contaminants, so the oil must be drained. However, the oil should be drained well before this stage is achieved systems.

Performance

Dispersants can also emulsify water and can provide some secondary benefits in corrosion and rust protection. In addition, because of their surfactancy, dispersants are attracted to metal surfaces and may provide some measure of protection against rust and corrosion formation by coating the metal surface. It works with other anti-rust and anti-corrosion additives in supreme way in formulations of industrial and automotive oils and greases.

It is oil soluble ashless dispersant recommended for engine oils, themic fluids, quenching oils at 0.5 to 1.5 % w/w.

Features

It has following additional performance benefits.

	It gives better performance at lower concentrations and also cost effective.
	Higher maximum protection due to high thermal stability.
	Easily miscible and flowable liquid.
	It has excellent reserved alkalinity which protects oil degradation.
	Even at higher concentrations it does not allow gum and lacquer/varnish formations.
	It prevents catalytic effect of the metal at higher temperatures.
	Compatible with all conventional automotive and industrial additives.

Typical Properties

TYPICAL PROPERTIES
Physical state	Liquid
Color	Amber
TBN	55
Flash Point °C COC min	160
Density @ 25 °C	0.95
Viscosity @ 100 °C., cSt.	25

Dosage: At 0.5 - 1.5 % treat level or as per requirements of formulators.

Peformance Test

IP 48, tested at 200 °C for 164 Hrs at flow rate of 10 litres/hr of air in typical formulations of compressor oils ISO VG 150 grade.

Viscosity rise without dispersant	47%
Viscosity rise with dispersant @ 0.5%	15%

2 T Oil Additives

This DI package contains dispersant, detergent, antioxidant, corrosion inhibitor along with defoamer, metal passivator of selected chemistry to meet the requirements of petrol engine performance.

At suitable dosages along with low molecular weight viscosity modifier and suitable solvent it covers the requirement of JASO FC and IS 14234 - 1996.

SPECIFICATIONS	TYPICAL VALUES
Viscosity @ 100 o C, cSt	68
Flash Point COC o C, min.	170
Density @ 29.5 o C	0.90
Sulphur % wt	0.7
TBN, mg KoH/gm	45
Sulfated ash % wt	0.5

Dosage: Typical dosage recommended is 4.0 % by weight. Along with PIB (22-25 % w/w) to meet JASO FC requirements

Thermic Oil Additive

It has been formulated to give excellent thermic fluid characteristics to cover a broad range of heat transfer applications. The product should be blended with highly refined base stocks by using special refining techniques.

Performance

When formulated with proper base stocks gives excellent chemical and oxidation stability with good heat transfer properties. It is non toxic and non corrosive.

Dosage: 1.0 % w/w in proper viscosity and type of base oils.

PROPERTIES	TYPICAL VALUES
Colour, ASTM, max.	5.0
Viscosity cSt, @ 100 oC	9
Flash Point oC., COC	140
Neut. No. mg KOH/gm	0.10
Pour Point, oC	(-)3
Cu. Strip Corrosion 3 hrs @ 100 oC (ASTM)	1

Sodium Petroleum Sulphonate

Sr. No.	CHARACTER	LIMITS	TYPICAL
1	APPEARANCE	DARK VISCOUS LIQUID	DARK VISCOUS LIQUID
2	SPECIFIC GRAVITY @ 15 ° C	1.00 – 1.10	1.00
3	SULPHONTE %WT	50 MIN	50.24
4	MINERAL OIL %WT	40 MAX	38.76
5	WATER % WT	5 MAX	0.1
6	MOLECULAR WEIGHT	430 – 450	445
7	ACID NUMBER mg KOH/GM	1 MAX	NIL
8	BASE NUMBER mg KOH/GM	1 MAX	0.47
9	INORGANIC SALTS, %WT	1.0	---
10	SOLUBILITY 5 % WT IN SN – 150	BRIGHT & CLEAR	BRIGHT & CLEAR
11	SOLUBILITY 10 % WT IN MTO	BRIGHT & CLEAR	BRIGHT & CLEAR
12	KINAMATIC VISCOSITY @ 100 ° C	---	171.45

Multi-functional Fuel Additive

Chemistry

An ash-less antioxidant - dispersant /surfactant type additive specially formulated for gasoline/diesel and jet fuels.

Features

It is an ash-less multifunctional additive developed for treatment of both gasoline and diesel fuels. It imparts the following Performance characteristics to the fuels:

	Fuel stability during storage.
	It has synergistic effect in the antiknock characteristics.
	Corrosion inhibition for pipeline and storage tanks.
	Water tolerance allowing moisture to settle rapidly from the fuel leaving no fuel emulsion in the water phase.
	Imparts reduction of carburetor deposits and exhaust emissions, induction system deposits, and engine sludge deposits.
	Injector cleanliness for diesel engines during prolonged performance life.
	Dispersancy for insoluble gum which may occur from the blending of distillate fuels or from presence of unstable fuel components.
	Drastically improves PUC due to complete burning of fuel hence improves fuel efficiency by 9 % to 30 % depending on conditions.

CHARACTERISTICS	TYPICAL VALUES
Specific gravity @ 15.6o C	0.84
Viscosity cSt., 40o C	3-9
Flash point o C	63
Pour Point o C	-12

Applications

The treating levels in ppm specified for different fuels are as follows: Treat level for diesel/gasoline in car engine applications suggested is 50-100 ppm.
